Fiber Interface Coatings

Scanning Electron Micrographs



Oxide Interface Coatings



Nitride Interface Coatings

SEM image of zirconium oxide interface coating on silicon carbide fibers



SEM image (cross-section) of zirconium oxide interface coating on carbon fibers (white rings around each fiber) showing outstanding uniformity of coverage achieved by UVCVD



SEM image showing fiber pullout in ceramic matrix composite with zirconium oxide interface coating





Nitride Interface Coatings



SEM image showing hafnium nitride interface coating on carbon fibers





Multilayered Interface Coatings



SEM image showing zirconium oxide/hafnium oxide/zirconium nitride multilayered interface coatings on carbon fibers



SEM image showing zirconium oxide/hafnium oxide multilayered interface coatings on carbon fibers
